Dallas 14 ft. x 20 ft. Gazebo Kit - Grey Structure

Structure color
Product Series Name

Imagine having a private getaway right in your garden or backyard. Add an entirely new quality to your yard by adding a Dallas Gazebo and turn it into the outdoor heart of your home.

The Dallas garden living space offers a sense of privacy and provides a completely shaded and protected area you can use all year-round. It’s ideal for your family get-together, hosting a barbecue bash or relaxing in your outdoor leisure spa and enjoying the fresh air and view of your garden.

This highly durable DIY gazebo is built to last with its combination of rust-resistant powder-coated aluminum frame and virtually unbreakable polycarbonate roof panels, protecting you from the sun’s harmful impact for many years of enjoyment. Enjoy outdoor quality living at its best!

  • Extra Large Structure: The large gazebo has the thickest aluminum column (18 cm) and beam (24 cm) profiles in the industry. It has only 4 posts, giving you even more room to enjoy.
  • Durable Frame, Modern Look: The aluminum powder-coated structure is durable, rust-resistant, and engineered to withstand harsh weather conditions. The modern gazebo design blends beautifully outdoors.
  • Unique Roofing System: The hardtop gazebo roof is UV-insulated, screw-free, and has built-in ventilation.
  • Resilient Panels: The 6mm virtually unbreakable, 100% UV protected, grey opaque twin-wall polycarbonate panels are high impact, shatter resistant, and insulating. No need to remove panels for Winter.
  • Wind and Snow Load: Withstands winds up to 110 km/hr / 68 mph and 80 kg/m² / 23 lbs./ft² of snow
  • Available Accessories: The metal gazebo can be fitted with both Palram – Canopia curtains and netting for a screened gazebo and perimeter/ internal lighting can be added (accessories sold separately)
  • Different Uses: The beauty of a patio gazebo is that there is no one way to enjoy it! It works just as well for outdoor lounging as it does for a hot tub or dining area.
  • Ready to Assemble: The structure arrives ready to assemble with pre-drilled profiles, pre-cut sliding panels and uses an easy sliding panel system. Please read all directions before you begin.
  • Warranty: This gazebo has a 10 Year Limited Warranty. Customers are responsible for ensuring a perfectly flat, leveled surface site for construction. We recommend using a solid base such as concrete or a wooden deck.
Model: #707107

Dimensions

A Length 606.3cm 19'11"ft
B Width 422cm 13'10"ft
C Height 207.5cm 6'10"ft
D Max Height 306.7cm 10'ft

Product Details

Resilient Panels

The 6mm virtually unbreakable, 100% UV protected, grey opaque twin-wall polycarbonate panels are high impact, shatter resistant, and insulating.

Extra Large Structure

The large gazebo has the thickest aluminum column (18 cm) and beam (24 cm) profiles in the industry and only 4 posts for more room The aluminum frame is durable, rust-resistant, and engineered to withstand harsh weather conditions.

Rating and Reviews

0 (0 Reviews)
Rating Breakdown
0
0
0
0
0
Post a review
Customer Reviews (0)

There are no reviews yet.

FAQ

The Martinique / Milano / Monaco / Palermo / Roma gazebo series do not have 2 different tracks, therefore cannot be installed together.
The gazebo can be set up on grass / dirt, however there should be concrete footings to attach the poles to.
There is a slight slope in order to make sure that water will runoff.
Yes, the Gazebo is UV resistant, and has gutters and gutter outlets to channel and allow rainwater collection.
The gazebo’s structure can support a ceiling fan hanging from it. Please make sure you install the fan and the wiring in a secure way, you may consult with a handyman as to how to attach it to the top.
Yes, you can use a small propane fire pit under the Garden Gazebo. Please make sure you follow the manufacturers’ safety advice and keep a safe distance.
Yes, it is recommended to anchor it to concrete / concrete slab.
A spray may compromise the polycarbonate’s integrity, it is not recommended to paint the panels. Please refer to the warranty.
Yes, this gazebo must be anchored. It comes with an anchoring and foot pads kit.
Yes, the polycarbonate panels can definitely stay on during winter season. There’s no need to remove the panels.

Foundation

A
Prepare the site

The product must be built on a solid anleveled surface in order to perform properly.

1 - Clear the site


2 - Level the ground


Important We recommend checking for restrictions or covenants for building this product in your area. In addition we advise to check if you need to submit any forms or if any permit is required prior to building the product.
B
Choose your foundation type
Option 1: Concrete / Wooden Deck

The screws and masonry anchors supplied with the kit are suitable for concrete fixing only. Please consult with an expert regarding which fasteners are suitable for other surfaces types (not supplied).




The screws and masonry anchors supplied with the kit are suitable for concrete fixing only. Please consult with an expert regarding which fasteners are suitable for other surfaces types (not supplied).

Option 2: Paving stones

Dig holes into the ground and fill with concrete. For frozen areas, please check the required depth needed for these holes.




Dig holes into the ground and fill with concrete. For frozen areas, please check the required depth needed for these holes.




Dig holes into the ground and fill with concrete. For frozen areas, please check the required depth needed for these holes.



a – 10 cm / 4″ | b + c – 40 cm / 1’4″

Option 3: Solid ground / Asphalt



a – 10 cm / 4″ | b + c – 40 cm / 1’4″

Option 3: Solid ground / Asphalt



a – 10 cm / 4″ | b + c – 40 cm / 1’4″



a + b + c – 40 cm / 1’4″

a + b + c – 40 cm / 1’4″

C
Dimensions



The Illustration describes center-to-center distance between poles.



Having purchased a longer carport, go to “Foundation Dimensions” page for further information.

C
Dimensions



The Illustration describes center-to-center distance between poles.



Having purchased a longer carport, go to “Foundation Dimensions” page for further information.
