Gazebo Kit Tucson 11 ft. x 14 ft.

Structure color
  • Gazebo kits Sturdy and durable structure – protects during harsh weather conditions.
  • Unique leak-free and screws-free roofing system
  • Rust-free, powder-coated aluminum gazebo and laser cut galvanized steel connectors.
  • Shatterproof, UV-protected 6 mm twin-wall polycarbonate roof panels.
  • Treated bronze glazing blocks harmful UV rays, transmits natural sunlight yet provides ample shading.
  • Built-in gutter system for effective water drainage & collection (dia. 5 cm / 2’)
  • Easy DIY gazebo assembly kit – pre-cut panels, pre-drilled profiles, and all screws included
  • Compact, efficient package to save storage space and shipping costs
  • The product requires a solid leveled surface for installation, such as a concrete or wooden base
  • The Gazebos are available in various sizes. Click to find more Gazebo kits.


A 435cm 14ft
B 359cm 11’9ft
C 242cm 7’11ft

Product Details

Gutter & gutter heads

Integrated gutter and gutter heads allow you to easily channel and collect rainwater for a sustainable irrigation system


Secure the carport to the surface of your choosing Structure can be easily relocated 6 Sturdy and durable 8.8 cm (3.15 in. x 3.15 in.) aluminum poles


The Martinique / Milano / Monaco / Palermo / Roma gazebo series do not have 2 different tracks, therefore cannot be installed together.
The gazebo can be set up on grass / dirt, however there should be concrete footings to attach the poles to.
There is a slight slope in order to make sure that water will runoff.
Yes, the Gazebo is UV resistant, and has gutters and gutter outlets to channel and allow rainwater collection.
The gazebo’s structure can support a ceiling fan hanging from it. Please make sure you install the fan and the wiring in a secure way, you may consult with a handyman as to how to attach it to the top.
Yes, you can use a small propane fire pit under the Garden Gazebo. Please make sure you follow the manufacturers’ safety advice and keep a safe distance.
Yes, it is recommended to anchor it to concrete / concrete slab.
A spray may compromise the polycarbonate’s integrity, it is not recommended to paint the panels. Please refer to the warranty.
Yes, this gazebo must be anchored. It comes with an anchoring and foot pads kit.
Yes, the polycarbonate panels can definitely stay on during winter season. There’s no need to remove the panels.

Assembly instructions for Downloads


Prepare the site

The product must be built on a solid anleveled surface in order to perform properly.

1 - Clear the site
2 - Level the ground

We recommend checking for restrictions or covenants for building this product in your area. In addition we advise to check if you need to submit any forms or if any permit is required prior to building the product.

Choose your foundation type
Option 1: Concrete / Wooden Deck

The screws and masonry anchors supplied with the kit are suitable for concrete fixing only. Please consult with an expert regarding which fasteners are suitable for other surfaces types (not supplied).

Group 7793@2x
Group 8332@2x
Option 2: Paving stones

Dig holes into the ground and fill with concrete. For frozen areas, please check the required depth needed for these holes.

Group 7798@2x
Group 7799@2x
Group 7800@2x
Option 3: Solid ground / Asphalt

a – 10 cm / 4″ | b + c – 40 cm / 1’4″

Option 3: Solid ground / Asphalt
Group 8497@2x
Group 8496@2x
Group 8495@2x

a + b + c – 40 cm / 1’4″

Group 8500

The Illustration describes center-to-center distance between poles.

Group 8498

Having purchased a longer carport, go to “Foundation Dimensions” page for further information.

Group 8499

The Illustration describes center-to-center distance between poles.

Group 8498

Having purchased a longer carport, go to “Foundation Dimensions” page for further information.
